1x16 Bare Fiber PLC Splitter

1x16 Bare Fiber PLC Splitter, G.657.A1 Single Mode Fiber Splitter

The Firsol 1x16 Bare Fiber PLC Splitter is a compact passive optical component designed to evenly divide one optical input signal into sixteen output signals. Manufactured using silica-based planar lightwave circuit technology, it provides low insertion loss, low polarization-dependent loss, excellent channel-to-channel uniformity, and stable performance across the 1260-1650 nm operating wavelength range. The splitter uses G.657.A1 bend-insensitive fiber and supports optical power up to 500 mW. With an insertion loss of ≤13.7 dB, loss uniformity of ≤1.0 dB, PDL of ≤0.3 dB, and a compact 50 x 7 x 4 mm bare fiber package, it is suitable for PON, FTTH, CATV, telecommunications networks, optical signal distribution systems, and integration into fiber optic modules and equipment.
