850nm Multimode In-Line Manual Variable Optical Attenuator
P/N: FIR-850-MM-IL-M-VOA|SKU: 10029
Unit Price
MOQ: 1 pcs
Production time varies based on product type, quantity, and customization level.
Below is a general estimate for most orders. For exact delivery time, please contact [email protected].
Shipping: FedEx / DHL / UPS Express · Tracking number provided after shipment
850nm Multimode In-Line Manual Variable Optical Attenuator
The 850nm Multimode In-Line Manual Variable Optical Attenuator provides adjustable optical attenuation at 850nm using a screw-driven mechanism for continuous and repeatable control. It is designed for multimode fiber systems and supports OM1/OM2/OM3/OM4 fibers. The device features a maximum insertion loss of ≤0.8 dB, an attenuation range of 0.8–60 dB, and a minimum return loss of ≥30 dB. The polarization dependent loss is ≤0.1 dB. The all-fiber in-line design requires no external power, allowing direct integration into multimode fiber optic systems. It supports a maximum continuous optical power of 500 mW and is suitable for testing, measurement, and system calibration.
Specifications
Parameter | Unit | Value |
|---|---|---|
Center Wavelength | nm | 850 |
Operating Wavelength Range | nm | ±40 |
Insertion Loss (Max.) | dB | 0.8 |
Attenuation Range | dB | 0.8 - 60 |
Polarization Dependent Loss | dB | ≤0.1 |
Return Loss (Min.) | dB | 30 |
Max Optical Power (CW) | mW | 500 |
Fiber Type | - | OM1/OM2/OM3/OM4 |
Tensile Load (Max.) | N | 5 |
Package Dimensions | mm | 26x18x8 |
Operating Temperature | °C | 0 to +70 |
Storage Temperature | °C | -40 to +85 |
Dimensions
