OS2 Single Mode 8 Fiber MTP®-8 To MTP®-8 Trunk Cable
P/N: FIR-OS2-8F-MTP8-TC|SKU: 11514
Total Price
$81.00 / unit
Production time varies based on product type, quantity, and customization level.
Below is a general estimate for most orders. For exact delivery time, please contact [email protected].
Shipping: FedEx / DHL / UPS Express · Tracking number provided after shipment
OS2 Single Mode 8 Fiber MTP®-8 To MTP®-8 Trunk Cable
OS2 Single Mode 8 Fiber MTP®-8 To MTP®-8 Trunk Cable is a high-density pre-terminated fiber optic cable designed for efficient backbone and structured cabling applications in data centers, telecom networks, and enterprise fiber infrastructures. Featuring MTP®-8 connectors on both ends, this trunk cable provides a compact 8-fiber solution for high-speed parallel optics applications, including 400G and emerging next-generation network deployments.
Built with OS2 single mode fiber, this MTP® trunk cable supports long-distance transmission with low insertion loss and excellent optical performance. It is available with various connector configurations, including MTP® connector gender, APC/UPC polishing options, polarity types, and customized cable lengths to meet different network deployment requirements.
Designed for reliable, space-saving installation, the MTP®-8 to MTP®-8 trunk cable helps reduce cable congestion and simplify fiber management in high-density environments. It is ideal for data center backbone links, fiber distribution areas, optical cross-connect systems, and high-performance communication networks.
Specifications
Connector A | US Conec MTP® Elite | Connector B | US Conec MTP® Elite |
Fiber Mode | OS2 9/125μm Single Mode | Wavelength | 1310/1550nm |
Fiber Count | 8 Fibers | Cable Diameter | 3.0mm |
Min. Bend Radius (Optical Fiber) | 10mm | Min. Bend Radius (Fiber Cable) | 10/5D (Dynamic/Static) |
Connector Durability | 500 Times | Tensile Strength | 80/240N (Long/Short Term) |
Insertion Loss | ≤0.35dB | Return Loss | ≥60dB (APC) |
Attenuation at 1310nm | ≤0.35dB/km | Attenuation at 1550nm | ≤0.21dB/km |
Operating Temperature | -10°C to +70°C | Storage Temperature | -20°C to +70°C |
8 Fibers MTP®-8 Trunk Cable Polarity Method
