FC/UPC OS2 Single Mode Simplex Fiber Pigtail
P/N: FIR-FCU-OS2S-FP|SKU: 12141
Total Price
$1.90 / unit
Production time varies based on product type, quantity, and customization level.
Below is a general estimate for most orders. For exact delivery time, please contact [email protected].
Shipping: FedEx / DHL / UPS Express · Tracking number provided after shipment
FC/UPC OS2 Single Mode Simplex Fiber Pigtail
The FC/UPC OS2 Single Mode Simplex Fiber Pigtail is designed for reliable fiber termination and fusion splicing in single mode optical networks. It features a factory-terminated FC/UPC connector on one end and an unterminated OS2 fiber end on the other, providing a practical solution for splicing into fiber distribution boxes, patch panels, ODFs, optical test equipment, and telecommunications systems.
Built with OS2 single mode fiber, this FC fiber pigtail offers low insertion loss, high return loss, and stable optical transmission performance. The FC connector uses a threaded coupling mechanism that provides a secure and mechanically stable connection, making it well suited for applications where vibration resistance and repeatable optical performance are important.
Various fiber lengths, cable diameters, and fiber configurations can be customized to meet different installation, laboratory, and network requirements.
Specifications
End A | FC/UPC | End B | Unterminated |
Fiber Type | OS2 9/125μm Single Mode | Wavelength | 1310/1550nm |
Fiber Count | 1 Fiber | Cable Diameter | 0.9/2.0mm |
Min. Bend Radius (Optical Fiber) | 10mm | Min. Bend Radius (Fiber Cable) | 10/5D (Dynamic/Static) |
Connector Durability | 1000 Times | Interchangeability | ≤0.2dB |
Insertion Loss | ≤0.3dB | Return Loss | ≥50dB |
Attenuation at 1310nm | ≤0.36dB/km | Attenuation at 1550nm | ≤0.22dB/km |
Operating Temperature | -10°C to +70°C | Storage Temperature | -40°C to +85°C |
PVC vs. LSZH vs. OFNP Fiber Cable Jacket Comparison
