LC/APC OS2 Single Mode Simplex Fiber Pigtail
P/N: FIR-LCA-OS2S-FP|SKU: 12107
Total Price
$1.90 / unit
Production time varies based on product type, quantity, and customization level.
Below is a general estimate for most orders. For exact delivery time, please contact [email protected].
Shipping: FedEx / DHL / UPS Express · Tracking number provided after shipment
LC/APC OS2 Single Mode Simplex Fiber Pigtail
The LC/APC OS2 Single Mode Simplex Fiber Pigtail is designed for low-loss fiber termination and fusion splicing in single mode optical networks. It features a factory-terminated LC/APC connector on one end and an unterminated OS2 fiber end on the other, providing a convenient solution for splicing into fiber distribution boxes, patch panels, ODFs, and optical communication equipment.
Built with OS2 single mode fiber and an APC polished connector, this fiber pigtail offers low insertion loss, high return loss, and reduced back reflection, making it especially suitable for applications that require stable optical performance and low reflectance. The compact LC connector also supports high-density fiber installations where space efficiency is important.
Various fiber lengths, cable diameters, and fiber configurations can be customized to meet different installation and network requirements.
Specifications
End A | LC/APC | End B | Unterminated |
Fiber Type | OS2 9/125μm Single Mode | Wavelength | 1310/1550nm |
Fiber Count | 1 Fiber | Cable Diameter | 0.9/2.0mm |
Min. Bend Radius (Optical Fiber) | 10mm | Min. Bend Radius (Fiber Cable) | 10/5D (Dynamic/Static) |
Connector Durability | 1000 Times | Interchangeability | ≤0.2dB |
Insertion Loss | ≤0.3dB | Return Loss | ≥60dB |
Attenuation at 1310nm | ≤0.36dB/km | Attenuation at 1550nm | ≤0.22dB/km |
Operating Temperature | -10°C to +70°C | Storage Temperature | -40°C to +85°C |
PVC vs. LSZH vs. OFNP Fiber Cable Jacket Comparison
